TWO HEADS BELT SANDER

Your current location:Home > Products > TWO HEADS BELT SANDER

TWO HEADS BELT SANDER

Details

CONFIGURATION:

PERFORMANCE FEATURE:

Beam base and hanging plate are precision castings, good stability and low noise.

Variable frequency helical-spiral bevel gear reducer for feeding, runs smoothly, low noise and durable.

Tapered sleeve pulley, compact structure and convenient installation.

TECHNICAL SPECIFACATIONS:

技术参数 Technical Specification SR- RP1000 SR- RP700 SR- R700
最大加工宽度 Max working width 1000mm 700mm 700mm
最短加工长度 Min working length 480mm 480mm 305mm
加工厚度 Working thinkness 2-160mm 2-160mm 2-160mm
输送速度(变频调速) Feeding speed 5-30m/min 5-30m/min 5-30m/min
砂带尺寸 Abrasave belt size 1030×2000mm 730×1900mm 730×1900mm
总功率 Total Moter power 39.94KW 28.24KW 28.24KW
工作压力 Working air pressure 0.6Mpa 0.6Mpa 0.6Mpa
压缩空气消耗量 Air consumption 12m3 /h 9m3 /h 9m3 /h
吸尘量 Volume of dust collection device 9800m 3 /h 8500m 3 /h 8500m 3 /h
外形尺寸 Overall dimensions 1663×2164×1980mm 1363×2164×1980mm 1363×2164×1980mm
重量 Net weight 2600kg 2300kg 2300kg
